Power Electronics & Green Energy Lab
Established Date: 2019 (According to laboratory registered book)
Financed by: BAUET own fund
Room No # 810 Panorama
Room Size: 42X27 =1134sft Students Capacity: 50
List of Equipment in the Power Electronics and Green Energy Laboratory:
| Sl. | Name of the Equipment and
Full Technical Specifications |
Total Qty. | Operating Condition
(Good) |
| 1 | Industrial Power Electronics Trainer Module
Brand: KL-500 |
18 Pcs | 16 Pcs |
| 2 | Digital Multi Meter
3-3 / 4 digits 4000 count 0.7% best accuracy Capacitance measurement (Not suitable for measurement of condensers with large leakage current) Frequency measurement (AC sine wave only) Data hold / Range hold Auto power off (30min.) (cancelable) AC frequency bandwidth : 40〜400Hz |
05 Pcs | 05 Pcs |
| 3 | Duel DC Power Supply Unit(32V,5Amp)
Brand: Dezhang Rating: 32V, 5Amp
|
01 Pcs | 01 Pcs |
| 4 | Bread Board
Brand: MCP |
12 Pcs | 12 Pcs |
| 5 | Digital Storage Oscilloscope(100MHz) (2 Chanel) Brand: Uni-T, Gw instek
Rating: 100MHz |
07 Pcs | 07 Pcs |
| 6 | Rheostat (37 Ohm, 1 Amp) | 13 Pcs | 13 Pcs |
| 7 | Oscilloscope Probe (100MHz)
Brand: Uni- T Rating: 20MHz |
03 Pcs | 03 Pcs |
| 8 | DC Regulated Power Supply
Yizhan Model-PS |
07 Pcs | 07 Pcs |
| 9 | Transformer (KL28010)
Delta/Star |
01 Pcs | 01 Pcs |
| 10 | MOSFET
IRFN540N |
100 Pcs | 100 Pcs |
| 11 | ATMEGA32A Microchip
PU1413 (40 pin) |
10 Pcs | 10 Pcs |
| 12 | ATMEGA32A Microchip
PU1718 (28 pin) |
10 Pcs | 10 Pcs |
| 13 | Transistor
CHN 718 (TYNG1.2M) |
94 Pcs | 94 Pcs |
| 14 | Miniature Circuit Breaker (MCB)
ABB SH 203T C32 |
08 Pcs | 08 Pcs |
| 15 | Nose pliers
Brand: Fujimoto. Rating: 6 inch. |
1 Pcs | 1 Pcs |
| 16 | Two pin Plug
Brand: Super Star Rating: -220V, 5A.
|
19 Pcs | 19 Pcs |
| 17 | Power Cable
Brand: Super Star Rating: 230V, 5A. |
07 Pcs | 07 Pcs |
| 18 | Multi plug (5 port, Brand-superstar/RFL Click)
Brand: superstar/RFL Click Rating:230 V |
01 Pcs | 01 Pcs |
| 19 | Screw Set
Brand: Jackley
|
1 Pcs | 1 Pcs |
| 20 | Lab Table
Made by wood Size (Length:84 Inch x Wide: 30 Inch) |
06 Pcs | 06 Pcs |
| 21 | Computer Table
Brand: Navana Furniture Size (Length: 44 Inch x Wide: 22 Inch) |
02 Pcs | 02 Pcs |
| 22 | Selling Fan
Product: Paradise Ceiling Fan Brand: Paradise Blade: Aluminum Size: 48″ & 56″ Speed: 320 RPM Power: 80w Motor: 100% copper Made: Bangladesh Warranty: 7 years |
13 Pcs | 13 Pcs |
| 23 | Almirah
Make By Janoni Still Furniture Size (Length: 72 Inch x Wide: 42 Inch |
02 Pcs | 02 Pcs |
| 24 | Rake (wood) | 01 Pcs | 01 Pcs |
| 25 | Student Table (Partex) | 07 Pcs | 07 Pcs |
| 26 | Tube Light
AC LED Flat Tube 18 Watt (2F) Daylight Lumen : 1800 Efficacy : 100 Beam Angle : 210° PF : 0.9 CRI : >80 Lifetime : 20,000 H. |
11 Pcs | 11 Pcs |
| 27 | Student Tool
Brand: Wood. Single Chair Made by wood Size (Length: 16 Inch x Wide: 14 Inch) |
50 Pcs | 50 Pcs |
| 28 | Lock with Key
Brand: HMBR |
01 Pcs | 01 Pcs |
| 29 | Solar Panel | 33 Pcs | 20 Pcs |
| 30 | Star screw driver | 01 Pcs | 01 Pcs |
| 31 | Flat type Screw driver | 02 Pcs | 02 Pcs |
| 32 | Green color Arduino Port (Cable) | 14 Pcs | 14 Pcs |
| 33 | Arduino | 14 Pcs | 14 Pcs |
| 34 | Bread board Connector | 40 Pcs | 40 Pcs |
| 35 | Chair | 02 Pcs | 02 Pcs |
| 36 | Fire Extinguisher | 02 Pcs | 02 Pcs |
Lab Management Committee
| Sl. No. | Name, Designation | Responsibility |
| 1. | Md. Roisul Ajom Ruku
Lecturer Dept. of Electrical and Electronic Engineering Contact No: 01793936855 E-mail: roisul.eee16.ruet@gmail.com |
In-Charge |
| 2. | Md. Saidul Islam
Lab Assistant Dept. of Electrical and Electronic Engineering Contact No.: 01742466090 E-mail: mdsislam090@gmail.com |
Member |
