Electronics Circuit Lab
The electronics circuit lab provides practical exposure to the student regarding the construction and operation of various electronics circuit like Ohm’s Law, Superposition Law, Nodal Analysis, Maximum Power Transfer Theorem, Reciprocity Theorem and so on and regarding the construction and operation of Diode, Zener Diode, Transistor (BJT & FET), Op-amps, Oscillator, Analog to Digital and Digital to Analog Converter. Through hands-on lab experiments, the course introduces students to various laboratory equipment and teaches them to experimentally implement and use circuits involving a multitude of electronics circuit.
Established Date: 23/08/2016 (According to laboratory registered book)
Financed by: BAUET own fund
Room No # 108 Panorama
Room Size: 42X27 =1134 sft Students Capacity: 50
List of Equipment in the Electronics Circuit Laboratory:
| Sl. | Name of the Equipment and
Full Technical Specifications |
Total Qty. | Operating Condition (Good) |
| 1 | Digital Multi Meter
3-3 / 4 digits 4000 count 0.7% best accuracy Capacitance measurement (Not suitable for measurement of condensers with large leakage current) Frequency measurement (AC sine wave only) Data hold / Range hold Auto power off (30min.) (cancelable) AC frequency bandwidth : 40〜400Hz |
7 Pcs | 07 Pcs |
| 2 | DC Power Supply Unit(32V,5Amp)
Brand: Dezhang Rating: 32V, 5Amp |
10 Pcs | 10Pcs |
| 3 | Bread Board
Brand: MCP |
10 Pcs | 10 Pcs |
| 4 | Power Project Board
Brand: Simco Rating: 15V |
7 Pcs | 07 Pcs |
| 5 | Digital Storage Oscilloscope(100MHz) (2 Chanel) Brand: Uni-T, Gw instek
Rating: 100MHz |
8 Pcs | 07 Pcs |
| 6 | Digital Storage Oscilloscope(200MHz) (4 Chanel) Brand: Uni- T
Rating: 200MHz |
2 Pcs | 02 Pcs |
| 7 | Oscilloscope Probe (100MHz)
Brand: Uni- T Rating: 20MHz |
15 Pcs | 15 Pcs |
| 8 | Function Generator
Gwinstek, GFG-8216A Produces sine, square, triangular, saw tooth (ramp), and pulse output. Arbitrary waveform generators can produce waves of any shape.[2] It can generate a wide range of frequencies. For example, the Tektronix FG 502 (ca 1974) covers 0.1 Hz to 11 MHz.[5] Frequency stability of 0.1 percent per hour for analog generators [5] or 500 ppm for a digital generator. Some function generators can be phase locked to an external signal source, which may be a frequency reference or another function generator. Amplitude modulation (AM), frequency modulation (FM), or phase modulation (PM) may be supported. |
10 Pcs | 6 Pcs |
| 9 | Function Generator(3MHz)
Brand: GW instek Rating: 3MHz |
5 Pcs | 1 Pcs |
| 10 | DC Ammeter (100mA/500mA/1A)
Brand: Sew Rating: 100mA/500mA/1A |
10 Pcs | 7 Pcs |
| 11 | DC Voltmeter (3V/10 V/15V)
Brand: Sew Rating: 3V/10 V/15V |
8 Pcs | 08 Pcs |
| 12 | Transformer
Brand: China Rating: 12*2 V |
20 Pcs | 20 Pcs |
| 13 | Variable Resistors
Brand: Rating: 10k, 50k,100k (Various type) |
30 Pcs | 30 Pcs |
| 14 | Diode(zener)
Rating: (3.3V, 3.6V, 4.3V, 4.7V, 5.1V ,5.6V ,6.2V ,7.5V, 9.1V, 10V) |
50 Pcs | 50 Pcs |
| 15 | FET
Rating: ±20V |
30 Pcs | 30 Pcs |
| 16 | Operational Amplifier
Brand: µA 741 Rating: ±18V |
50 Pcs | 50 Pcs |
| 17 | SCR
Brand: BT151 Rating: 12A,500V |
30 Pcs | 30 Pcs |
| 18 | DIAC
Brand: DB3 Rating: 32V |
50 Pcs | 50 Pcs |
| 19 | TRIAC
Brand: BTA 16 Rating: 16A, 600V |
50 Pcs | 50 Pcs |
| 20 | UJT
Brand: 2N2646 Rating: 2A |
50 Pcs | 50 Pcs |
| 21 | Resistor: Various type
Brand: Philips Rating: .25 W |
2500 Pcs | 2500 Pcs |
| 22 | Resistor
High Reliability 220 ohm Resistor Power Rating of 0.25 Watts ±5% Tolerance Carbon Film Type Excellent Heat and Humidity Withstand Performance Ideal for Use as Jumper or Link RoHS Compliant Long Life Durable and easy to install Very convenient and practical |
50 Pcs | 50 Pcs |
| 23 | Inductor: Various type
Rating:1µH,1.5 µH,2.2 µH,3.3 µH,4.7 µH,5.6 µH. |
100 Pcs | 100 Pcs |
| 24 | Circuit Breaker (SPST),(6Amp)
Brand: Superstar. Rating: 230V, 6Amp |
14 Pcs | 14 Pcs |
| 25 | Nose pliers
Brand: Fujimoto. Rating: 6 inch. |
1 Pcs | 1 Pcs |
| 26 | Cutting Pliers
Brand: Fujimoto. Rating: 6 inch. |
1 Pcs | 1Pcs |
| 27 | Combination Pliers
Brand: Fujimoto. Rating: 6 inch. |
1 Pcs | 1Pcs |
| 28 | Soldering Iron (60 Watt)
Brand: Makita. Rating: 60 Watt |
5 Pcs | 5 Pcs |
| 29 | Resister Tray/Chamber
Brand: RFL Rating: |
6 Pcs | 6 Pcs |
| 30 | Soldering Rosen
Brand: Baku. Rating: 20gm |
5 Pcs | 5 Pcs |
| 31 | Soldering Wire
Brand: Baku Rating: .8mm, 50gm |
5 Pcs | 5 Pcs |
| 32 | Rectifier Diode- 1N4007
Polarity: Cathode Indicated by Polarity Band Typical Reverse Recovery Time is 30uSec. Forward Rectifier DC Current up to 1Amp. |
100 Pcs | 100 Pcs |
| 33 | Resister Box
Brand: Voltcraft
|
2 Pcs | 2 Pcs |
| 34 | 555 TIMER
Rating:16V |
50 Pcs | 50 Pcs |
| 35 | Resistor Holder
Rating: 5W |
3 Pcs | 3Pcs |
| 36 | Various Capacitor
Rating:0.1µF,0.01µF,0.001µF,1µF,10µF,4.7µF,100µF,1000µF. |
300 Pcs | 300 Pcs |
| 37 | Transistor BC-547
Brand: BC-547 Rating: 80 V, 100mA. |
50 Pcs | 50 Pcs |
| 38 | Transistor/BJT(BD-135)
Brand: BD-135 Rating: 45V, 1A. |
50 Pcs | 50 Pcs |
| 39 | LED Various
Rating: 5V |
50 Pcs | 50 Pcs |
| 40 | BRUSH
Brand: Wickes Rating: 4inc |
1 Pcs | 1 Pcs |
| 41 | Air Blower
Brand: Makita Rating: 600W |
1 Pcs | 1 Pcs |
| 42 | Voltage Regulator IC
Brand: L 7805 Rating: 5V |
50 Pcs | 50 Pcs |
| 43 | Voltage Regulator IC (LM 7912)
Brand: LM 7912 Rating: -12V |
50 Pcs | 50 Pcs |
| 44 | Two pin Plug
Brand: Super Star Rating: -220V, 5A. |
7 Pcs | 7 Pcs |
| 45 | Power Cable
Brand: Super Star Rating: 230V, 5A. |
13 Pcs | 13 Pcs |
| 46 | Multiplug (5 port, Brand-superstar/RFL Click)
Brand: superstar/RFL Click Rating:230 V |
2 Pcs | 2 Pcs |
| 47 | Screw Set
Brand: Jackley |
1 Pcs | 1 Pcs |
| 48 | Lab Table
Made by wood Size (Length:84 Inch x Wide: 30 Inch) |
10 Pcs | 10 Pcs |
| 49 | Computer Table
Brand: Navana Furniture Size (Length: 44 Inch x Wide: 22 Inch) |
1 Pcs | 1Pcs |
| 50 | Selling Fan
Product: Paradise Ceiling Fan Brand: Paradise Blade: Aluminum Size: 48″ & 56″ Speed: 320 RPM Power: 80w Motor: 100% copper Made: Bangladesh Warranty: 7 years |
8 Pcs | 8 Pcs |
| 51 | Almirah
Make By Janoni Still Furniture Size (Length: 72 Inch x Wide: 42 Inch |
3 pcs | 3 Pcs |
| 52 | Tube Light
AC LED Flat Tube 18 Watt (2F) Daylight Lumen : 1800 Efficacy : 100 Beam Angle : 210° PF : 0.9 CRI : >80 Lifetime : 20,000 H. |
4 pcs | 4 Pcs |
| 53 | Multimedia
Projector+Remote Brand Name: Epson Model: EB-972 Projection System: 3LCD, 3-chip technology Native Resolution: 1024 x 768 (XGA) Color Brightness: 4100 lumens Up to 17,000 hours in ECO Mod |
1 Pcs | 1 Pcs |
| 54 | Student Tool
Brand: Wood. Single Chair Made by wood Size (Length: 16 Inch x Wide: 14 Inch) |
50 Pcs | 50 Pcs |
Lab Management Committee
| Sl. No. | Name, Designation | Responsibility |
| 1. | Ashik Alam
Assistant Professor Dept. of Electrical and Electronic Engineering Contact No: 01769146230 E-Mail: ashik.alam.eee@bauet.ac.bd |
In-Charge |
| 2. | Md. Nur Alom Shahin
Assistant Technical Officer Dept. of Electrical and Electronic Engineering Contact No: 01768-307221 E-mail: mdnurulalomshahin6141@gmail.com |
Member |
